Designing website architecture for LLM crawling: a complete strategy for topic clustering and internal linking

LLM does not crawl the entire site and then rank, but instantly grabs the most relevant paragraphs to spell out answers. This article explains how to use topic clusters and internal links to reorganize the website structure so that every page can be cleanly extracted by the AI ​​engine and judged as a trusted source, and an execution sequence that can be implemented within 90 days is attached.

Tenten GEO TeamPublished 2026-07-124 min read
A central hub and peripheral clusters of illuminated nodes and connecting lines symbolize the website architecture designed for LLM search.

LLM will not crawl your entire site first and then decide the ranking like Google does. When the user asks a question, it instantly grabs a few pieces of content that are judged to be the most relevant, spells them out as an answer, and then attaches a source link. The goal that your website architecture should serve has therefore changed: not to push the homepage to the first place, but to allow each paragraph to be individually picked out, understood, and marked as a trusted source. Most B2B SaaS websites are architected for keyword rankings from ten years ago and will lose a lot of points under this new set of rules.

LLM reads your website, which is different from Google

The logic of traditional crawlers is to include the entire page, calculate the link weight, and give the entire page a score. The process of a generative engine is different: it first cuts the web page into segments (usually one to several paragraphs), establishes a vector index for each segment, and only sends the most relevant segments into the model when answering questions. The unit being quoted is the paragraph, not the page. If your focus is hidden in a long narrative that the reader has to piece together, the engine is likely to only pick up half of it, or skip it altogether.

Pushing it up determines how the entire site should be organized. The engine must first find your page, determine which topic it belongs to, and then confirm whether you have talked deeply enough about this topic before it will include you as a candidate when asking related questions. The job of the architecture is to make these three things clear: what is this page talking about, which pages on the site it shares the same topic with, and whether you have covered this topic completely.

Topic cluster: Let the engine confirm that you are an authority on a certain topic

Topic clusters are currently the best architecture for aligning LLM retrieval logic. Choose a core topic, write a pillar page that covers the whole picture, and then write a series of cluster pages around it that each go into a single subtopic, all linked together into a group. When the engine sees a cluster of pages that are linked to each other, have consistent terms, and complement each other, it is easier to judge you as a reliable source of this topic, rather than an isolated article.

The pillar page is responsible for "broadness": explaining the definition, scope, and decision-making structure of the topic, so that readers and engines can grasp the overall situation on one page. Cluster pages are responsible for "deepness": one page only solves one specific problem, such as "How to write the anchor text of internal links" or "Should GPTBot be allowed in robots.txt". The division of labor between the two should be clean; if the same subtopic is scattered across three or four pages and dilutes each other, the engine will not know which page to quote.

  • A pillar page: covers the entire core topic, is usually longer, and serves as the entrance to the entire cluster.
  • Six to twelve article series pages: Each article locks a sub-topic that can form an independent article, and the title itself is a real issue.
  • Two-way links: Each cluster page links back to the pillar page, and the pillar page also links to each cluster page in the corresponding paragraph.
  • Consistent terminology: The entire cluster uses the same set of words. One page is called "generative engine" and the other page is called "AI search" to reduce the understanding cost of the engine.
  • There are no orphan pages: any page must be connected to at least two pages in the cluster, otherwise the crawler may not be able to reach it at all.
Topic cluster architecture diagram: The central pillar page connects multiple cluster pages with two-way internal links to form a topic authority that can be recognized by the engine.
A pillar page links multiple sub-topic cluster pages, and internal links allow LLM to treat the entire cluster as an authoritative source for the same topic.

Many people still think of "passing weight" when making internal links, treating links as pipelines that lead scores back and forth. For LLM search, internal links are more like a semantic map, telling the engine which pages are talking about the same thing and what their superior and subordinate relationships are. Anchor text is particularly critical. Those few words are often the most direct clue for the engine to determine "what topic this link leads to." Therefore, use content words that can describe the topic of the target page. Don't use "click here" or "learn more." The location of links also makes a difference: links embedded in the context of the text and semantically coherent with the context are worth more than the entire row of related articles at the end of the page.

So that every page can be extracted cleanly

The structure is right, but the single page itself must be easy to draw. When the engine crawls a piece of content, it prefers self-contained paragraphs: a point is explained together with the necessary context in one paragraph, and there is no need to scroll forward three paragraphs to understand it. Put the conclusion at the beginning of the paragraph, only talk about one thing in a paragraph, and use descriptive subtitles to divide the paragraphs into paragraphs. The extraction hit rate will be significantly increased. The title level should also correspond to the real level. H2 and H3 should be in a nested shape, don’t skip levels randomly for layout; then adding clean FAQ and Article structured data is equivalent to delineating the key points for the engine first. These details are inconspicuous on their own, but cumulatively determine whether you will be cited. Tenten GEO's GEO audit is to take stock of the cluster structure, internal links and accessibility of the entire website at once and find out the broken links.

If you can't climb in, all the talk ahead will be in vain.

No matter how good the architecture is, if the AI crawler cannot enter, everything will be reset to zero. This level is the most overlooked and the most deadly, and is worth checking quarterly.

  • Does robots.txt block AI crawlers by mistake: GPTBot, ClaudeBot, PerplexityBot, and Google-Extended. Please confirm whether you have deliberately allowed them or blocked them accidentally.
  • Is the core content rendered by front-end JavaScript? Many AI crawlers do not execute JS, and all they see is an empty shell. The key content must exist in the HTML source code.
  • Whether the site map (sitemap.xml) is complete and up-to-date, giving crawlers an authoritative list of pages.
  • Loading speed and server response of important pages: Once timeouts occur frequently or 5xx are returned, the crawler will reduce the crawling frequency or even give up.

How can I schedule it within 90 days?

  1. The first step is to take stock of the existing content and group it by topic to see which topics have been clustered and which are only scattered single articles.
  2. The second step is to add or rewrite a pillar page for each key topic to explain the full picture of the topic.
  3. The third step is to complete the internal links of the cluster pages, eliminate orphan pages, and unify the terminology of the entire cluster.
  4. Step 4: Fix accessibility: Check robots.txt, confirm core content is in HTML, and update sitemap.
  5. The fifth step is to use the visibility tracking tool to monitor your citations in each engine, and use the data to decide which question to fill in in the next round.

Website architecture is the least sexy part of GEO, but the most difficult to quickly implement. It's not as immediate as changing a few titles, but once the skeleton of clusters and links is right, every new piece of content you write will add points to the existing authority, rather than working alone. If you want to first figure out where your architecture misses in LLM retrieval, you can schedule a 30-minute GEO diagnosis, and we will directly point out your cluster breakpoints and accessibility gaps.

Frequently asked questions

What is the difference between topic clusters and general blog categories?
Categories just label and archive articles, while topic clusters use one pillar page plus multiple sub-topic cluster pages, and then string them together with two-way internal links, so that the AI engine can identify that you have covered this topic completely and are worthy of citation.
How should I write the anchor text of internal links to facilitate LLM retrieval?
Use content words that describe the topic of the target page as anchors, such as "Internal linking principles of generative engines" instead of "Click here" or "Learn more". Those few words are the most direct clues for the engine to determine which topic the link leads to.
Should I allow AI crawlers in robots.txt?
If you want to be referenced by AI engines, you should allow crawlers such as GPTBot, ClaudeBot, PerplexityBot, and Google-Extended. First confirm whether it is deliberately blocked or accidentally blocked. The blocked pages cannot be retrieved or quoted.
